Attribute
| Bremsen | Shimano Deore BR-MT420, 4 pistons, PM, Shimano Deore BR-MT420, 4 pistons, PM, 203 mm |
| Bremshebel | Shimano BL-MT401, Aluminium |
| Rahmen | Haibike HY5AF7D440, Steckachse M12 (1.00) x 148mm, Scheibenbremse Post Mount, Federweg: 140mm |
| Schaltung | Shimano CUES RD-U6000 10s, Shadow+, 10-Gang |
| Schalthebel | Shimano CUES SL-U6000, Rapidfire+, Rapidfire |
| Gabel | SR Suntour XCR34 Boost (2 Pos. Lever) 140 mm |
| Dämpfer | RockShox Deluxe Select 205x57,5mm, Trunnion, DebonAir+ |
| Dämpfer Federweg (mm) | 140,00 |
| Pedale | XLC VPE-527 MTB Alloy Pedal w. Reflector |
| Zahnkranz | Samox Direct Mount Chainring 38T, Shimano Cues CS-LG300-10, HG, 11-48T |
| Antrieb | Shimano CN-LG500 10s, Linkglide |
| Lenker | Haibike Components TheBar ++ Dia. 31.8 mm 780 mm |
| Griffe | Velo VLG-1751D2, MTB Grips |
| Vorbau | Haibike The Stem++ Ahead JD-ST161A, L: 35 mm (S) / L: 60 mm (M-XL) |
| Steuersatz | Acros Blocklock 164° ZS44/ZS56 |
| Felgen | Rodi TRYP 30 Disc 32H with eyelets |
| Reifen | Schwalbe Nobby Nic Performance, 60-622, Schwalbe Nobby Nic Performance, 65-584 |
| Naben | Shimano HB-TC500-15-B, Boost 15x110 mm, Centerlock, Shimano FH-TC500-HM-B, Boost 12x148 mm, Centerlock |
| Speichen | Sapim Leader Dia. 2.0 mm |
| Sattel | Selle Royal Vivo |
| Sattelstütze | JD SP20T.1A Dia. 34.9 mm, L: 350 mm |
| Sattelklemmung | Seatclamp HL-Corp |
| Zulässiges Gesamtgewicht (kg) | 120,00 |
| Motor | Yamaha PW-S2, 250 W, 75 Nm, 25 km/h |
| Akku | Yamaha InTube |
| Display | Yamaha A2 Display |
| Akku-Kapazität (Wh) | 720,00 |
| Reach (mm) | 436,00 |
| Stack (mm) | 652,00 |
| Steuerrohrwinkel (Grad) | 66,00 |
| Sitzrohrwinkel (Grad) | 75,00 |
| Kettenstrebenlänge (mm) | 460,00 |
| Steuerrohrlänge (mm) | 130,00 |
| Tretlagerabsenkung (mm) | 17,00 |
| Gabelvorbiegung (mm) | 44,00 |
| Gabeleinbauhöhe (mm) | 570,00 |
| Lenker Breite | 7800,00 |
| Radstand (mm) | 1221,00 |
| Tretlagerhöhe (mm) | 346,00 |
| Bremsscheiben | Shimano SM-RT30 203 mm, Centerlock, Shimano RT-EM300 |
| Ladegerät | Yamaha Standard Charger 4A |
| Bremse vorne | Shimano Deore BR-MT420, 4 pistons, PM |
| Bremse hinten | Shimano Deore BR-MT420, 4 pistons, PM, 203 mm |
| Bremshebel Vorderrad | Shimano BL-MT401, Aluminium |
| Bremsscheibe vorne | Shimano SM-RT30 203 mm, Centerlock |
| Bremsscheibe hinten | Shimano RT-EM300 |
| Felge vorne | Rodi TRYP 30 Disc 32H with eyelets |
| Reifen vorne | Schwalbe Nobby Nic Performance, 60-622 |
| Reifen hinten | Schwalbe Nobby Nic Performance, 65-584 |
| Nabe vorne | Shimano HB-TC500-15-B, Boost 15x110 mm, Centerlock |
| Nabe hinten | Shimano FH-TC500-HM-B, Boost 12x148 mm, Centerlock |
| Drehmoment des Motors (Nm) | 85,00 |
